CA6900长途客车乘客门及舱门设计(论文-DWG图纸)

摘要

乘客门是客车的重要组成部分，是乘客上下车的通道，对客车的整体造型也起着重要的协调作用。随着我国汽车技术的发展，在长途车中我国汽车厂家已普遍采用了优势突出的外摆式乘客门。外摆式乘客门是一种无轨道的移出车门，门扇靠回转臂支撑，依靠转轴的转动带动门扇作近似于平行移动的运动，因而也称为平移门。

本文兼容外摆式乘客门和发动机舱门的设计。分析了外摆式乘客门和发动机舱门的工作原理以及其各部分的尺寸和一些主要零件的选型和安装。讨论了国内外客车附件工业的发展状况的比较。本次设计应用了CAD进行设计外摆式乘客门和发动机舱门.

关键词：外摆门，发动机舱门，CAD。

Abstract

Passenger door is the important department of the coach, is the route wayfor the passengers. And assort withthe whole coach sculpt. With the developmentof our vehicle technology, the domesticvehicle factory has already adoptedthe outer turning service door. It has much more predominance. The outer turning service door is the door which has no tram roadand parallelmove out of the coach, thedoor was supported by the circumrotate arm. By the rotationof the circumrotate axes, the door is moving close to the parallelmove. Thus this door is called translation door.

This paper introducesthe design ofthe outer turning service door and the Engine cabin door.Analyzed the structure and operating principles ofthe outer turning service door and the Engine cabin door,determinedthe size of its parts and major components of the models and installation. Discussed the development of thevehicle annex industry.Application in this design the CAD software create inthe outer turning service door and the Engine cabin door.

Key word: the outer turning service door, the Engine cabin door,CAD

目录

第一章概论

1.1乘客门的类型……………………………………………………1

1.1.1乘客门的主要结构形式 ………………………………………1

1.2外摆门的优缺点……………………………………………………1

1.2 CAD技术的发展……………………………………………………2

第二章国内外发展情况比较

2.1客车附件工业的特点…………………………………………3

2.2 目前国内客车车身附件的状况及与国外发达国家之间的差距………………………………………………………………3

2.3对客车附件的发展建议……………………………………5

第三章外摆式乘客门设计

3.1 外摆式乘客门的结构…………………………………………7

3.2乘客门泵选型……………………………………………………9

3.2.1门泵安装与调试………………………………………………11

3.3运动机构设计及校核……………………………………………12

3.3.1用作图法确定车门的运动轨迹…………………………12

3.3.2运动校核……………………………………………………15

3.4 外摆门的密封………………………………………………15

3.5外摆式乘客门的制作

3.5.1制作工艺………………………………………………………16

3.5.2预装与调试……………………………………………………17

3.6车门玻璃的安装…………………………………………17

4.发动机舱门设计

4.1舱门结构组成………………………………………………18

4.2零部件选型

4.2.1锁具的选择………………………………………………18

4.2.2气弹簧支撑机构……………………………………………19

4.3铰链设计………………………………………………21

设计评价分析…………………………………………26

致谢………………………………………………27

参考文献………………………………………………28
